Cisco Catalyst C9300-48T-E 48-Port Data-Only Enterprise Switch | Network Essentials
Cisco Catalyst 9300 48-Port Data-Only Enterprise Switch, Network Essentials (C9300-48T-E)
Quick Buying Guide - Best for Standard Data-Intensive Access
-
Network Essentials License: Provides robust Layer 2 switching and foundational Layer 3 routing (Static, RIP, OSPF Stub), making it ideal for standard campus and branch deployments without the overhead of SD-Access.
-
High-Density Data Ports: Offers 48 Gigabit Ethernet data-only ports, perfectly optimized for environments where Power over Ethernet (PoE) is not required, thus reducing overall power consumption and costs.
-
Modular Uplinks: Future-proof your network with a hot-swappable uplink slot supporting 1G, 10G, 25G, or 40G network modules to adapt to growing bandwidth needs.
-
High Availability: Built-in StackWise-480 technology provides 480 Gbps of stacking bandwidth with sub-50ms failover, ensuring a highly resilient network edge.
-
Pro Tip: This switch delivers excellent value for standard, non-PoE network environments like workstation clusters or server rooms. If your enterprise requires full network automation (SD-Access) or advanced routing protocols like BGP, you must choose the Network Advantage model (C9300-48T-A) instead.
Product Overview
The Cisco Catalyst C9300-48T-E is a high-performance 1 RU fixed-access enterprise campus switch designed for data-intensive, mission-critical networks. Running the modern Cisco IOS XE operating system with the Network Essentials license, it delivers streamlined, software-driven connectivity for your campus or branch.
Powered by a robust multicore x86 CPU and the programmable Cisco UADP 2.0 ASIC, the C9300-48T-E offers 48 auto-sensing 10/100/1000 RJ-45 data downlinks alongside highly flexible modular uplinks. By eliminating the PoE power overhead, this switch focuses entirely on delivering wire-speed, non-blocking performance while maximizing energy efficiency.
Core Highlights
-
48 Gigabit Data Ports: 48 auto-sensing RJ-45 downlinks designed purely for high-density, high-speed data connectivity.
-
Flexible Modular Uplinks: One dedicated network-module slot supporting 1G (C9300-NM-4G), 10G (C9300-NM-8X), 25G (C9300-NM-2Y), or 40G (C9300-NM-2Q) connectivity.
-
Wire-Speed Performance: Delivers 256 Gbps non-blocking switching capacity (up to 736 Gbps when stacked) and a forwarding rate of 190.47 Mpps (up to 547.62 Mpps stacked).
-
StackWise-480 Resiliency: Stack up to 8 switches into a single logical entity with 480 Gbps of bidirectional stacking bandwidth, streamlining management and boosting redundancy.
-
Enterprise-Grade Security: Equipped with line-rate AES-256 MACsec encryption, Secure Boot, and a Trust Anchor Module (TAM) for robust protection against advanced threats.
-
Programmability & Telemetry: Native support for NETCONF, RESTCONF, YANG models, and streaming telemetry for proactive network assurance and automation.
Use Cases & Deployment Scenarios
-
Enterprise Office & Workstation Access: Provides highly reliable, wire-speed data connectivity for high-density office layouts, standard PCs, and network printers.
-
Server Room & Data Center Edge (ToR): Serves as an efficient Top-of-Rack data switch for servers and storage appliances where PoE is unnecessary.
-
Cost-Effective Campus Aggregation: Delivers powerful Layer 2 and basic Layer 3 forwarding for educational campuses and large branch offices.
-
High-Availability Edge: Utilize StackWise-480 stacking and cross-stack EtherChannel for environments requiring maximum uptime and simplified network management.
Recommended Accessories
| Accessory Category | Part Number | Description |
| Network Module | C9300-NM-8X | 8 x 10G/1G SFP+ uplink module for high-speed campus aggregation. |
| Network Module | C9300-NM-2Y | 2 x 25G/10G/1G SFP28 uplink module for low latency and high bandwidth. |
| Network Module | C9300-NM-4G | 4 x 1G SFP uplink module for standard fiber connectivity. |
| Power Supply | PWR-C1-350WAC-P | 350W AC Platinum-rated PSU (Default for data-only models). |
| Stacking Cable | STACK-T1-50CM | 50 cm data stack cable for StackWise-480 interconnectivity. |
| Fan Module | FAN-T2= | Field-replaceable fan module for N+1 cooling redundancy. |
Comparison with Similar Models
| Feature | C9300-48T-E | C9300-48T-A | C9300-48P-E |
| Downlinks | 48 x 1G Data | 48 x 1G Data | 48 x 1G PoE+ |
| Software License | Network Essentials | Network Advantage | Network Essentials |
| Advanced L3 & SD-Access | Not Supported | Supported | Not Supported |
| Available PoE Power | None | None | 437W (Default) |
| Switching Capacity | 256 Gbps | 256 Gbps | 256 Gbps |
| Stacking Bandwidth | 480 Gbps | 480 Gbps | 480 Gbps |
Specifications
| Parameter | Specification |
| Product Code | C9300-48T-E |
| Software License | Cisco IOS XE with Network Essentials |
| Downlink Ports | 48 x 10/100/1000 Mbps RJ-45 data-only ports |
| Modular Slot | 1 hot-swappable NM slot (supports 1G/10G/25G/40G) |
| Switching Capacity | 256 Gbps (standalone); 736 Gbps (stacked) |
| Forwarding Rate | 190.47 Mpps (standalone); 547.62 Mpps (stacked) |
| MAC Address Table | 32,000 entries |
| CPU / Memory | Multicore x86 CPU; 8 GB DRAM; 16 GB Flash |
| Dimensions (HWD) | 1.73" x 17.5" x 17.7" (4.4 x 44.5 x 44.9 cm) with default PSU |
| Weight | 16.43 lb (7.45 kg) |
| MTBF | 305,870 hours |
| Operating Temp. | 23 F to 113 F (-5°C to 45°C) |
